Sample of layout for TLE5010-11 sensor PCB - included in MMjoy2 package, folder PCB. Sample of Diode Matrix connections (using BU0836 as example): Http:/ / / showthread.php?t=120049ĭebolestis PCB Layout for make DIY Shift Register boards (Cougar/Warthog compatible): Skip the DIY build boards part (first posts - like here) with today available and cheap Arduino boards the DIY ones became obsolete. Related topics in Russian language forums: Https:/ / / site/ mmjoyproject/ fajly-dla-skacivania
#Xpadder 5.3 failed to set data error download#
To maximize the MCU (Arduino board) pins use:įor axis - MCP3208 external ADC, what allow use 8 channel 12 bit (4096 poins of resolution), and free 4 pins on Arduino and allow 8 analog axis inputs.įor buttons - shift register IC 74HC165 or CD 4021B (this free 3 pins on Arduino and allow UNLIMITED button sources chaining one Shift Register IC in another, each manage 8 buttons)Ĭompatible Arduino boards - should use ATMEGA3244, ST90USB646, ST90USB1286 m/c (16 MHZ, 5V):įor MMJoy firmware/Configurator download see the more recently Mega_Mozg links (end of topic), or there: Possibility to use for keyboard emulation: 12 buttons (or 15 without "mouse") Possibility to use for mouse emulation: 3 buttons + 2 axis Possibility to use for joystick: 128 buttons + 2 HAT's (8 buttons) + 8 axis
#Xpadder 5.3 failed to set data error windows#
If you want configure MMJoy as "2 axis and 1(or 0) button joystick" you can.įirmware has support for up to 128 buttons + 10 axis inputs (2 axis reserved for mouse emulation, Windows Game Controllers see up to 8 axis), number of buttons use depend on Arduino board number of pins available. "Joystick" name, VID, PID defined be user as desired, allowing use several MMjoy2 in the same computer. Compatibility with shift registers used in F-22 PRO, Cougar, Warthog and Cobra M-5 grips, making use this grips "plug-and-play". "Shift" (mode) function, allow a physical button press a virtual button if "shift" are ON. HALL sensor: Radiometric linear, example Honeywell SS495A1, Allegro A1324 Sample o DIY Shift Register board, by Debolesis (ED forum).Įncoder - up to 6, adjustable "click" timesĪxis: Up to 8 axis using the internal 10 bits (1024 points) ADC or up to 8 axis using 12 bits (4096 position) using external ADC MCP3201, 3202, 3204, 3208 (the last digit indicates supported axis number)Ĭonventional potentiometer, Linear type (B code), 1k to 100k, ideally use 10k. Sample of firmware upload, using Teensy 2.0+: http:/ / / topic/ 18379-teensy-20-mmjoy2-firmware-joystick-controllerīuttons: Up to 128 - Notice that 128 buttons was possible in some boards only due pinout limitations, see in links bellow.īuttons connection require use of Diode Matrix or Shift Register circuits. Tutorial for firmware upload - by Geneb(F15SIM): http:/ / mmjoy2/ pro-micro-instructions.pdf
Https:/ / / j2e3t3v5z/ Teensy2.jpgįirmware and MMJoySetup download: https:/ / / site/ mmjoyproject/ fajly-dla-skacivania <<< Always check if MJoySetup and firmware are with same date (or redundance error will occur).
#Xpadder 5.3 failed to set data error pro#
IMPORTANT - Arduino PRO MICRO with ATMEGA43u4, 16 MHZ, 5V.įirmware : MMjoy2 - is loaded in Arduino board through a USB cable with MMJoy2 JoySetup software: Hardware needed: ~5$ Arduino PRO Micro ( ATMEGA32U4) clone (or ~20$ Sparkfun/Teensy versions).
Solder tools and skill is need to assembly pins in some Arduino boards, as well to attach potentiometer, sensor, buttons as in any joystick.
#Xpadder 5.3 failed to set data error code#
A free firmware developed by Mega_Mozg13 for make USB joystick controller using specific versions of Arduino/Teensy prototype boards, without need to assembly circuit boards or write computer code or deal with Arduino "sketches".
